4 Ohm RMS Power: 284W x 4 channels

2 Ohm RMS Power: 460W x 4 channels

4 Ohm RMS Bridged Power: 888W x 2 channels

Frequency Response: 10Hz – 23KHz

Signal to Noise: 95dB

Damping Factor: 150

Input Sensitivity: 6V – 0.2V

CH1/2 & Ch3/4 Filters:

• High Pass Filter: 20Hz – 800Hz with a multiplier of x1, x10 (200Hz-8KHz)

• Low Pass Filter: 50Hz – 800Hz with a multiplier of x1, x10 (500Hz-8KHz)

• Bandpass Capable

• Clip in/Clip out for Ch1/2 & Ch3/4

Input Connections:

• 0 Gauge Input for Power and Ground

• Up to 12 Gauge Input on Speakers

• Tiffany Style RCA Connection

Working Voltage: 9 to 15.5 Volts

Dimensions: 340mm L x 190mm W x 57mm H (13.38 x 7.48 x 2.24 inches)
